Decision Tree for Regression in R Programming Last Updated : 28 Jul, 2020 Comments Improve Suggest changes Like Article Like Report Decision tree is a type of algorithm in machine learning that uses decisions as the features to represent the result in the form of a tree-like structure. It is a common tool used to visually represent the decisions made by the algorithm. Decision trees use both classification and regression. Regression trees are used when the dependent variable is continuous whereas the classification tree is used when the dependent variable is categorical. For example, determining/predicting gender is an example of classification, and predicting the mileage of a car based on engine power is an example of regression. In this article, let us discuss the decision tree using regression in R programming with syntax and implementation in R programming. Implementation in R In R programming, rpart() function is present in rpart package. Using the rpart() function, decision trees can be built in R. Syntax: rpart(formula, data, method) Parameters: formula: indicates the formula based on which model has to be fitted data: indicates the dataframe method: indicates the method to create decision tree. "anova" is used for regression and "class" is used as method for classification. Example 1: In this example, let us predict the sepal width using the regression decision tree. Step 1: Install the required package Python3 # Install the package install.packages("rpart") Step 2: Load the package Python3 # Load the package library(rpart) Step 3: Fit the model for decision tree for regression Python3 # Create decision tree using regression fit <- rpart(Sepal.Width ~ Sepal.Length + Petal.Length + Petal.Width + Species, method = "anova", data = iris) Step 4: Plot the tree Python3 # Output to be present as PNG file png(file = "decTreeGFG.png", width = 600, height = 600) # Plot plot(fit, uniform = TRUE, main = "Sepal Width Decision Tree using Regression") text(fit, use.n = TRUE, cex = .7) # Saving the file dev.off() Step 5: Print the decision tree model Python3 # Print model print(fit) Step 6: Predicting the sepal width Python3 # Create test data df <- data.frame (Species = 'versicolor', Sepal.Length = 5.1, Petal.Length = 4.5, Petal.Width = 1.4) # Predicting sepal width # using testing data and model # method anova is used for regression cat("Predicted value:\n") predict(fit, df, method = "anova") Output: n= 150 node), split, n, deviance, yval * denotes terminal node 1) root 150 28.3069300 3.057333 2) Species=versicolor, virginica 100 10.9616000 2.872000 4) Petal.Length=4.05 84 7.3480950 2.945238 10) Petal.Width< 1.95 55 3.4920000 2.860000 20) Sepal.Length=6.35 19 0.6242105 2.963158 * 11) Petal.Width>=1.95 29 2.6986210 3.106897 22) Petal.Length=5.25 22 2.0277270 3.168182 * 3) Species=setosa 50 7.0408000 3.428000 6) Sepal.Length=5.05 22 1.7859090 3.713636 * Predicted value: 1 2.805556 Example 2: In this example, let us predict the mpg value using a decision tree for regression. Step 1: Install the required package Python3 # Install the package install.packages("rpart") Step 2: Load the package Python3 # Load the package library(rpart) Step 3: Fit the model for decision tree for regression Python3 # Create decision tree using regression fit <- rpart(mpg ~ disp + hp + cyl, method = "anova", data = mtcars ) Step 4: Plot the tree Python3 # Output to be present as PNG file png(file = "decTree2GFG.png", width = 600, height = 600) # Plot plot(fit, uniform = TRUE, main = "MPG Decision Tree using Regression") text(fit, use.n = TRUE, cex = .6) # Saving the file dev.off() Step 5: Print the decision tree model Python3 # Print model print(fit) Step 6: Predicting the mpg value using test dataset Python3 # Create test data df <- data.frame (disp = 351, hp = 250, cyl = 8) # Predicting mpg using testing data and model cat("Predicted value:\n") predict(fit, df, method = "anova") Output: n= 32 node), split, n, deviance, yval * denotes terminal node 1) root 32 1126.04700 20.09062 2) cyl>=5 21 198.47240 16.64762 4) hp>=192.5 7 28.82857 13.41429 * 5) hp< 192.5 14 59.87214 18.26429 * 3) cyl< 5 11 203.38550 26.66364 * Predicted value: 1 13.41429 Advantages of Decision Trees Considers all the possible decisions: Decision trees considers all the possible decisions to create a result of the problem. Easy to use: With classification and regression techniques, it is easy to use for any type of problem and further creating predictions and solving the problem. No problem with missing values: There is no problem with the datasets having missing values and do not affect the decision tree building. Disadvantages of Decision Trees Requires higher time: Decision trees requires higher time for the calculation for large datasets. Less learning: Decision trees are not good learners. Random forest approach is used for better learning. Comment More infoAdvertise with us Next Article Decision Tree Classifiers in R Programming U utkarsh_kumar Follow Improve Article Tags : R Language R Machine-Learning R regression R Data-science Similar Reads Machine Learning with R Machine Learning as the name suggests is the field of study that allows computers to learn and take decisions on their own i.e. without being explicitly programmed. These decisions are based on the available data that is available through experiences or instructions. It gives the computer that makes 2 min read Getting Started With Machine Learning In RIntroduction to Machine Learning in RMachine learning in R allows data scientists, analysts and statisticians to build predictive models, uncover patterns and gain insights using powerful statistical techniques combined with modern machine learning algorithms. R provides a comprehensive environment with numerous built-in functions and 6 min read What is Machine Learning?Machine learning is a branch of artificial intelligence that enables algorithms to uncover hidden patterns within datasets. It allows them to predict new, similar data without explicit programming for each task. Machine learning finds applications in diverse fields such as image and speech recogniti 9 min read Setting up Environment for Machine Learning with R ProgrammingMachine Learning is a subset of Artificial Intelligence (AI) which enables systems to learn and make predictions without explicit programming. In machine learning, algorithms and models are developed to identify patterns and trends within data, allowing systems to predict outcomes based on observed 2 min read Supervised and Unsupervised Learning in R ProgrammingMachine Learning (ML) is a subset of Artificial Intelligence (AI) that enables computers to learn from data and improve their performance over time without being explicitly programmed. The choice of ML algorithms depends on the type of data and the task at hand which can be broadly divided into Supe 3 min read Data ProcessingIntroduction to Data in Machine LearningData refers to the set of observations or measurements to train a machine learning models. The performance of such models is heavily influenced by both the quality and quantity of data available for training and testing. Machine learning algorithms cannot be trained without data. Cutting-edge develo 4 min read ML | Understanding Data ProcessingIn machine learning, data is the most important aspect, but the raw data is messy, incomplete, or unstructured. So, we process the raw data to transform it into a clean, structured format for analysis, and this step in the data science pipeline is known as data processing. Without data processing, e 5 min read ML | Overview of Data CleaningData cleaning is a important step in the machine learning (ML) pipeline as it involves identifying and removing any missing duplicate or irrelevant data. The goal of data cleaning is to ensure that the data is accurate, consistent and free of errors as raw data is often noisy, incomplete and inconsi 13 min read ML | Feature Scaling - Part 1Feature Scaling is a technique to standardize the independent features present in the data in a fixed range. It is performed during the data pre-processing. Working: Given a data-set with features- Age, Salary, BHK Apartment with the data size of 5000 people, each having these independent data featu 3 min read Supervised Learning Simple Linear Regression in RRegression shows a line or curve that passes through all the data points on the target-predictor graph in such a way that the vertical distance between the data points and the regression line is minimum What is Linear Regression?Linear Regression is a commonly used type of predictive analysis. Linea 12 min read Multiple Linear Regression using RPrerequisite: Simple Linear-Regression using RLinear Regression: It is the basic and commonly used type for predictive analysis. It is a statistical approach for modeling the relationship between a dependent variable and a given set of independent variables.These are of two types:  Simple linear Re 3 min read Decision Tree for Regression in R ProgrammingDecision tree is a type of algorithm in machine learning that uses decisions as the features to represent the result in the form of a tree-like structure. It is a common tool used to visually represent the decisions made by the algorithm. Decision trees use both classification and regression. Regres 4 min read Decision Tree Classifiers in R ProgrammingClassification is the task in which objects of several categories are categorized into their respective classes using the properties of classes. A classification model is typically used to, Predict the class label for a new unlabeled data objectProvide a descriptive model explaining what features ch 4 min read Random Forest Approach in R ProgrammingRandom Forest in R Programming is an ensemble of decision trees. It builds and combines multiple decision trees to get more accurate predictions. It's a non-linear classification algorithm. Each decision tree model is used when employed on its own. An error estimate of cases is made that is not used 4 min read Random Forest Approach for Regression in R ProgrammingRandom Forest approach is a supervised learning algorithm. It builds the multiple decision trees which are known as forest and glue them together to urge a more accurate and stable prediction. The random forest approach is similar to the ensemble technique called as Bagging. In this approach, multip 3 min read Random Forest Approach for Classification in R ProgrammingRandom forest approach is supervised nonlinear classification and regression algorithm. Classification is a process of classifying a group of datasets in categories or classes. As random forest approach can use classification or regression techniques depending upon the user and target or categories 4 min read Classifying data using Support Vector Machines(SVMs) in RSupport Vector Machines (SVM) are supervised learning models mainly used for classification and but can also be used for regression tasks. In this approach, each data point is represented as a point in an n-dimensional space where n is the number of features. The goal is to find a hyperplane that be 5 min read Support Vector Machine Classifier Implementation in R with Caret packageOne of the most crucial aspects of machine learning that most data scientists run against in their careers is the classification problem. The goal of a classification algorithm is to foretell whether a particular activity will take place or not. Depending on the data available, classification algori 7 min read KNN Classifier in R ProgrammingK-Nearest Neighbor or KNN is a supervised non-linear classification algorithm. It is also Non-parametric in nature meaning , it doesn't make any assumption about underlying data or its distribution. Algorithm Structure In KNN algorithm, K specifies the number of neighbors and its algorithm is as fol 4 min read Evaluation MetricsPrecision, Recall and F1-Score using RIn machine learning, evaluating model performance is critical. Three widely used metrics—Precision, Recall, and F1-Score—help assess the quality of classification models. Here's what each metric represents:Recall: Measures the proportion of actual positive cases correctly identified. Also known as s 3 min read How to Calculate F1 Score in R?In this article, we will be looking at the approach to calculate F1 Score using the various packages and their various functionalities in the R language. F1 Score The F-score or F-measure is a measure of a test's accuracy. It is calculated from the precision and recall of the test, where the precisi 5 min read Unsupervised LearningK-Means Clustering in R ProgrammingK Means Clustering is an unsupervised learning algorithm that groups data into clusters based on similarity. This algorithm divides data into a specified number of clusters, assigning each data point to one. It is used in various fields like banking, healthcare, retail and media. In this article we 3 min read Hierarchical Clustering in R ProgrammingHierarchical clustering in R Programming Language is an Unsupervised non-linear algorithm in which clusters are created such that they have a hierarchy(or a pre-determined ordering). For example, consider a family of up to three generations. A grandfather and mother have their children that become f 3 min read How to Perform Hierarchical Cluster Analysis using R Programming?Cluster analysis or clustering is a technique to find subgroups of data points within a data set. The data points belonging to the same subgroup have similar features or properties. Clustering is an unsupervised machine learning approach and has a wide variety of applications such as market research 5 min read Linear Discriminant Analysis in R ProgrammingOne of the most popular or well established Machine Learning technique is Linear Discriminant Analysis (LDA ). It is mainly used to solve classification problems rather than supervised classification problems. It is basically a dimensionality reduction technique. Using the Linear combinations of pre 6 min read Model Selection and EvaluationCross-Validation in R programmingThe major challenge in designing a machine learning model is to make it work accurately on the unseen data. To know whether the designed model is working fine or not, we have to test it against those data points which were not present during the training of the model. These data points will serve th 9 min read LOOCV (Leave One Out Cross-Validation) in R ProgrammingLOOCV (Leave-One-Out Cross-Validation) is a cross-validation technique where each individual observation in the dataset is used once as the validation set, while the remaining observations are used as the training set. This process is repeated for all observations, with each one serving as the valid 4 min read Bias-Variance Trade Off - Machine LearningIt is important to understand prediction errors (bias and variance) when it comes to accuracy in any machine-learning algorithm. There is a tradeoff between a model’s ability to minimize bias and variance which is referred to as the best solution for selecting a value of Regularization constant. A p 3 min read Reinforcement LearningMarkov Decision ProcessMarkov Decision Process (MDP) is a way to describe how a decision-making agent like a robot or game character moves through different situations while trying to achieve a goal. MDPs rely on variables such as the environment, agent’s actions and rewards to decide the system’s next optimal action. It 4 min read Q-Learning in Reinforcement LearningQ-Learning is a popular model-free reinforcement learning algorithm that helps an agent learn how to make the best decisions by interacting with its environment. Instead of needing a model of the environment the agent learns purely from experience by trying different actions and seeing their results 7 min read Deep Q-Learning in Reinforcement LearningDeep Q-Learning is a method that uses deep learning to help machines make decisions in complicated situations. It’s especially useful in environments where the number of possible situations called states is very large like in video games or robotics.Before understanding Deep Q-Learning it’s importan 4 min read Dimensionality ReductionIntroduction to Dimensionality ReductionWhen working with machine learning models, datasets with too many features can cause issues like slow computation and overfitting. Dimensionality reduction helps to reduce the number of features while retaining key information. Techniques like principal component analysis (PCA), singular value decom 4 min read ML | Introduction to Kernel PCAPRINCIPAL COMPONENT ANALYSIS: is a tool which is used to reduce the dimension of the data. It allows us to reduce the dimension of the data without much loss of information. PCA reduces the dimension by finding a few orthogonal linear combinations (principal components) of the original variables wit 6 min read Principal Component Analysis with R ProgrammingPrincipal component analysis(PCA) in R programming is an analysis of the linear components of all existing attributes. Principal components are linear combinations (orthogonal transformation) of the original predictor in the dataset. It is a useful technique for EDA(Exploratory data analysis) and al 3 min read Advanced TopicsKolmogorov-Smirnov Test in R ProgrammingKolmogorov-Smirnov (K-S) test is a non-parametric test employed to check whether the probability distributions of a sample and a control distribution, or two samples are equal. It is constructed based on the cumulative distribution function (CDF) and calculates the greatest difference between the em 4 min read Moore – Penrose Pseudoinverse in R ProgrammingThe concept used to generalize the solution of a linear equation is known as Moore – Penrose Pseudoinverse of a matrix. Moore – Penrose inverse is the most widely known type of matrix pseudoinverse. In linear algebra pseudoinverse A^{+}    of a matrix A is a generalization of the inverse matrix. The 5 min read Spearman Correlation Testing in R ProgrammingCorrelation is a key statistical concept used to measure the strength and direction of the relationship between two variables. Unlike Pearson’s correlation, which assumes a linear relationship and continuous data, Spearman’s rank correlation coefficient is a non-parametric measure that assesses how 3 min read Poisson Functions in R ProgrammingThe Poisson distribution represents the probability of a provided number of cases happening in a set period of space or time if these cases happen with an identified constant mean rate (free of the period since the ultimate event). Poisson distribution has been named after Siméon Denis Poisson(Frenc 3 min read Feature Engineering in R ProgrammingFeature engineering is the process of transforming raw data into features that can be used in a machine-learning model. In R programming, feature engineering can be done using a variety of built-in functions and packages. One common approach to feature engineering is to use the dplyr package to mani 7 min read Adjusted Coefficient of Determination in R ProgrammingPrerequisite: Multiple Linear Regression using R A well-fitting regression model produces predicted values close to the observed data values. The mean model, which uses the mean for every predicted value, commonly would be used if there were no informative predictor variables. The fit of a proposed 3 min read Mann Whitney U Test in R ProgrammingA popular nonparametric(distribution-free) test to compare outcomes between two independent groups is the Mann Whitney U test. When comparing two independent samples, when the outcome is not normally distributed and the samples are small, a nonparametric test is appropriate. It is used to see the di 4 min read Bootstrap Confidence Interval with R ProgrammingBootstrapping is a statistical method for inference about a population using sample data. It can be used to estimate the confidence interval(CI) by drawing samples with replacement from sample data. Bootstrapping can be used to assign CI to various statistics that have no closed-form or complicated 5 min read Like
