Basic Constructions - Angle Bisector, Perpendicular Bisector, Angle of 60° Last Updated : 31 Aug, 2021 Comments Improve Suggest changes Like Article Like Report Most of the time we use diagrams while depicting the shapes and scenarios in mathematics. But they are not precise, they are just a representation of the actual shape without proper measurements. But when we are building something like a wooden table, or map of a building is to be constructed. It needs to be precise in measurements. For such cases, we need to learn to do some basic constructions. Let's study them in detail. Introduction to Constructions To draw polygons, angles, or circles some basic instruments are needed which are given in our geometry box. A geometry box should contain the following instruments: 1. A ruler or graduated scale: It should have centimetres and millimetres marked off on one side and the other side should have inches and their parts marked off on it. 2. Pair of Set Squares: One should have 60°, 90° and 30° as its angles and the other one should have 90°, 45° and 45°. 3. Divider Dividers have a jointed pair of legs, each leg has a sharp point. They can be used for scribing a circles and taking off and transferring the dimensions. 4. Compass Compass is used for inscribing circles or arcs. As similar to dividers, they can also be used for taking off and transferring the dimensions. 5. Protractor This instruments helps us in measuring the angles. It has degrees marked from 0 to 180 and from 180 to 0. It has readings from both left to right and right to left. Both the readings supplement each other. For learning about the basic constructions we will mostly use three of them. Graduated Scale, Compass, and a Protractor. Let's see some basic constructions. Basic Constructions We know that a bisector is a line that divides anything into two equal parts, be it an angle or a line segment. Let's see how to make bisectors of any given angle using our instruments from the geometry box. Construction 1: Angle Bisector Let's say we are given an angle PQR and the goal is to construct a bisector of the given angle. Steps for Construction: Step 1. Take Q as centre and draw an arc that intersects the rays QP and QR with any radius. Let's name the intersection points T and S. Step 2. Now take T and S as the Centre and with the radius that is more than half of the length of TS. Draw arcs such that they intersect, let's call that intersection U. Step 3. Now join QU, this is our required bisector. Construction 2: Perpendicular bisector of the given line. A perpendicular bisector is a line that bisects the given line and is perpendicular to it. Given a line PQ, the goal is to construct a perpendicular bisector. Steps for Construction: Step 1. Let's take P and Q as the centre and take any radius that more than half the length of PQ. Now draw arcs on both sides of the line PQ and let them intersect at A and B respectively. Step 2. Now Join AB and let it intersect at M on PQ. This is our required perpendicular bisector. Construction 3: An angle of 60° The goal in this construction is to construct an angle of 60° from a given ray PQ. Steps of Construction: Step 1. With P as the centre and some arbitrary radius, construct a circular arc that intersects PQ at S. Step 2. Now take S as the centre and the same radius as above. Draw an arc on the arc already drawn. Let's say the point of intersection of both arcs is T. Step 3. Draw a ray PR passing through T. This will give us the required angle of 60°. Let's see some examples on these concepts. Sample Problems Question 1: In the figure below, ∠PQR is divided into many parts. Determine the bisector for ∠PQR. Solution: We know that bisector of an angle divides it into two equal parts. Notice that, ∠PQT = ∠SQT + ∠PQS ∠PQT = 30° + 20° ∠PQT = 50° and, ∠TQR = ∠TQU + ∠UQR ∠TQR = 35° + 15° ∠TQR = 50° This the ray QT is the bisector of the angle PQR. Question 2: State True or False for the statements below. Perpendicular bisector bisects a line segment. An angle bisector divides an angle into two equal parts. Solution: Statement 1: False According to the definition of perpendicular bisector, it is a line that divides a line segment into two equal parts and is also perpendicular to it. Statement 2: True An angle bisector divides an angle into two equal parts. Question 3: Construct an angle of 30° using the construction techniques mentioned above. Solution: Steps of Construction: Step 1. Using the construction technique mentioned above for creating 60° angle. Let's call that angle ∠CAB. Step 2. Now, since the angle is 60° and out goal is to construct an angle of 30°. We need to bisect this angle using the technique mentioned above. Now the ray AE gives us the angle of 30°. Question 4: Construct an angle of 135°. Solution: An angle of 135° can be made using one 90° and one 45°. Let's make a straight line PQ with a point R in between. Now we have made two 90° angles. We need to bisect on the of angles to make a 45°. Thus, ∠PRE gives us the required angle 135°. Comment More infoAdvertise with us Next Article Basic Constructions - Angle Bisector, Perpendicular Bisector, Angle of 60° A anjalishukla1859 Follow Improve Article Tags : Mathematics School Learning Class 9 Maths-Class-9 Similar Reads CBSE Class 9 Maths Revision Notes CBSE Class 9th Maths Revision Notes is an important phase of student’s life when they’re at a turning point in their life. The reason being class 9 is the foundation level to succeed in class 10. As you know, students must complete Class 9 in order to sit for Class 10 board examinations. Also, it la 15+ min read Chapter 1: Number SystemNumber System in MathsNumber System is a method of representing numbers on the number line with the help of a set of Symbols and rules. These symbols range from 0-9 and are termed as digits. Let's learn about the number system in detail, including its types, and conversion.Number System in MathsNumber system in Maths is 13 min read Natural Numbers | Definition, Examples & PropertiesNatural numbers are the numbers that start from 1 and end at infinity. In other words, natural numbers are counting numbers and they do not include 0 or any negative or fractional numbers.Here, we will discuss the definition of natural numbers, the types and properties of natural numbers, as well as 11 min read Whole Numbers - Definition, Properties and ExamplesWhole numbers are the set of natural numbers (1, 2, 3, 4, 5, ...) plus zero. They do not include negative numbers, fractions, or decimals. Whole numbers range from zero to infinity. Natural numbers are a subset of whole numbers, and whole numbers are a subset of real numbers. Therefore, all natural 10 min read Prime Numbers | Meaning | List 1 to 100 | ExamplesPrime numbers are those natural numbers that are divisible by only 1 and the number itself. Numbers that have more than two divisors are called composite numbers All primes are odd, except for 2.Here, we will discuss prime numbers, the list of prime numbers from 1 to 100, various methods to find pri 12 min read Rational NumbersRational numbers are a fundamental concept in mathematics, defined as numbers that can be expressed as the ratio of two integers, where the denominator is not zero. Represented in the form p/q​ (with p and q being integers), rational numbers include fractions, whole numbers, and terminating or repea 15+ min read Irrational Numbers- Definition, Examples, Symbol, PropertiesIrrational numbers are real numbers that cannot be expressed as fractions. Irrational Numbers can not be expressed in the form of p/q, where p and q are integers and q ≠0.They are non-recurring, non-terminating, and non-repeating decimals. Irrational numbers are real numbers but are different from 12 min read Real NumbersReal Numbers are continuous quantities that can represent a distance along a line, as Real numbers include both rational and irrational numbers. Rational numbers occupy the points at some finite distance and irrational numbers fill the gap between them, making them together to complete the real line 10 min read Decimal Expansion of Real NumbersThe combination of a set of rational and irrational numbers is called real numbers. All the real numbers can be expressed on the number line. The numbers other than real numbers that cannot be represented on the number line are called imaginary numbers (unreal numbers). They are used to represent co 6 min read Decimal Expansions of Rational NumbersReal numbers are simply the combination of rational and irrational numbers, in the number system. In general, all the arithmetic operations can be performed on these numbers and they can be represented in the number line, also. So in this article let's discuss some rational and irrational numbers an 6 min read Representation of Rational Numbers on the Number Line | Class 8 MathsRational numbers are the integers p and q expressed in the form of p/q where q>0. Rational numbers can be positive, negative or even zero. Rational numbers can be depicted on the number line. The centre of the number line is called Origin (O). Positive rational numbers are illustrated on the righ 5 min read Operations on Real NumbersReal Numbers are those numbers that are a combination of rational numbers and irrational numbers in the number system of maths. Real Number Operations include all the arithmetic operations like addition, subtraction, multiplication, etc. that can be performed on these numbers. Besides, imaginary num 9 min read Rationalization of DenominatorsRationalization of Denomintors is a method where we change the fraction with an irrational denominator into a fraction with a rational denominator. If there is an irrational or radical in the denominator the definition of rational number ceases to exist as we can't divide anything into irrational pa 8 min read Nth RootNth root of unity is the root of unity when taken which on taking to the power n gives the value 1. Nth root of any number is defined as the number that takes to the power of n results in the original number. For example, if we take the nth root of any number, say b, the result is a, and then a is r 6 min read Laws of Exponents for Real NumbersLaws of Exponents are fundamental rules used in mathematics to simplify expressions involving exponents. These laws help in solving arithmetic problems efficiently by defining operations like multiplication, division, and more on exponents. In this article, we will discuss the laws of exponent for r 6 min read Chapter 2: PolynomialsPolynomials in One Variable | Polynomials Class 9 MathsPolynomials in One Variable: Polynomial word originated from two words “poly†which means “many†and the word “nominal†which means “termâ€. In maths, a polynomial expression consists of variables known as indeterminate and coefficients. Polynomials are expressions with one or more terms with a non-z 7 min read Polynomial FormulaThe polynomial Formula gives the standard form of polynomial expressions. It specifies the arrangement of algebraic expressions according to their increasing or decreasing power of variables. The General Formula of a Polynomial:f(x) = an​xn + an−1​xn−1 + ⋯ + a1​x + a0​Where,an​, an−1​, …, a1​, a0​ a 5 min read Types of Polynomials (Based on Terms and Degrees)Types of Polynomials: In mathematics, an algebraic expression is an expression built up from integer constants, variables, and algebraic operations. There are mainly four types of polynomials based on degree-constant polynomial (zero degree), linear polynomial ( 1st degree), quadratic polynomial (2n 9 min read Zeros of PolynomialZeros of a Polynomial are those real, imaginary, or complex values when put in the polynomial instead of a variable, the result becomes zero (as the name suggests zero as well). Polynomials are used to model some physical phenomena happening in real life, they are very useful in describing situation 13 min read Factorization of PolynomialFactorization in mathematics refers to the process of expressing a number or an algebraic expression as a product of simpler factors. For example, the factors of 12 are 1, 2, 3, 4, 6, and 12, and we can express 12 as 12 = 1 × 12, 2 × 6, or 4 × 3.Similarly, factorization of polynomials involves expre 10 min read Remainder TheoremThe Remainder Theorem is a simple yet powerful tool in algebra that helps you quickly find the remainder when dividing a polynomial by a linear polynomial, such as (x - a). Instead of performing long or synthetic division, you can use this theorem to substitute the polynomial and get the remainder d 8 min read Factor TheoremFactor theorem is used for finding the roots of the given polynomial. This theorem is very helpful in finding the factors of the polynomial equation without actually solving them.According to the factor theorem, for any polynomial f(x) of degree n ≥ 1 a linear polynomial (x - a) is the factor of the 10 min read Algebraic IdentitiesAlgebraic Identities are fundamental equations in algebra where the left-hand side of the equation is always equal to the right-hand side, regardless of the values of the variables involved. These identities play a crucial role in simplifying algebraic computations and are essential for solving vari 14 min read Chapter 3: Coordinate GeometryCoordinate GeometryCoordinate geometry is a branch of mathematics that combines algebra and geometry using a coordinate plane. It helps us represent points, lines, and shapes with numbers and equations, making it easier to analyze their positions, distances, and relationships. From plotting points to finding the short 3 min read Cartesian Coordinate SystemCartesian Coordinate System in Maths is a division of coordinate geometry where the location of a point in a plane or space is marked by a pair of numbers or three numbers. The branch of geometry that deals with the Cartesian Coordinate System is called Coordinate Geometry. The numbers which are use 15+ min read Cartesian PlaneCartesian plane is defined as the two-dimensional plane used in the Cartesian coordinate system. This plane is formed by intersecting two perpendicular lines called the x-axis and the y-axis and their intersection is called the origin. This method of distributing the 2-Dimensional space into four ar 9 min read Chapter 4: Linear equations in two variablesLinear Equations in One VariableLinear equation in one variable is the equation that is used for representing the conditions that are dependent on one variable. It is a linear equation i.e. the equation in which the degree of the equation is one, and it only has one variable.A linear equation in one variable is a mathematical stat 7 min read Linear Equation in Two VariablesLinear Equation in Two Variables: A Linear equation is defined as an equation with the maximum degree of one only, for example, ax = b can be referred to as a linear equation, and when a Linear equation in two variables comes into the picture, it means that the entire equation has 2 variables presen 9 min read Graph of Linear Equations in Two VariablesLinear equations are the first-order equations, i.e. the equations of degree 1. The equations which are used to define any straight line are linear, they are represented as, x + k = 0; These equations have a unique solution and can be represented on number lines very easily. Let's look at linear e 5 min read Graphical Methods of Solving Pair of Linear Equations in Two VariablesA system of linear equations is just a pair of two lines that may or may not intersect. The graph of a linear equation is a line. There are various methods that can be used to solve two linear equations, for example, Substitution Method, Elimination Method, etc. An easy-to-understand and beginner-fr 8 min read Chapter 5: Introduction to Euclid's GeometryEuclidean GeometryEuclidean geometry is the study of 2-Dimensional geometrical shapes and figures. Euclidean geometry is based on different axioms and theorems. The word geometry is derived from the Greek words ‘geo’ meaning Earth and ‘metrein’ meaning ‘To measure’. Thus, geometry is the measure of the Earth or vario 15 min read Equivalent Version of Euclid’s Fifth PostulateGeometry has originated from a variety of civilizations. Almost every major civilization has studied and used geometry in its prime. Egyptian and Indian civilizations were more focused on using geometry as a tool. Euclid came and changed the way people used to think in geometry. Instead of making it 6 min read Chapter 6: Lines and AnglesLines and AnglesLines and Angles are the basic terms used in geometry. They provide a base for understanding all the concepts of geometry. We define a line as a 1-D figure that can be extended to infinity in opposite directions, whereas an angle is defined as the opening created by joining two or more lines. An ang 9 min read Types of AnglesTypes of Angles: An angle is a geometric figure formed by two rays meeting at a common endpoint. It is measured in degrees or radians. It deals with the relationship of points, lines, angles, and shapes in space. Understanding different types of angles is crucial for solving theoretical problems in 10 min read Pairs of Angles - Lines & AnglesWhen two lines share a common endpoint, called Vertex then an angle is formed between these two lines and when these angles appear in groups of two to display a specific geometrical property then they are called pairs of angles. Understanding these angle pairs helps in solving geometry problems invo 8 min read Transversal LinesTransversal Lines in geometry is defined as a line that intersects two lines at distinct points in a plane. The transversal line intersecting a pair of parallel lines is responsible for the formation of various types of angles that, include alternate interior angles, corresponding angles, and others 7 min read Angle Sum Property of a TriangleAngle Sum Property of a Triangle is the special property of a triangle that is used to find the value of an unknown angle in the triangle. It is the most widely used property of a triangle and according to this property, "Sum of All the Angles of a Triangle is equal to 180º." Angle Sum Property of a 8 min read Chapter 7: Triangles Triangles in GeometryA triangle is a polygon with three sides (edges), three vertices (corners), and three angles. It is the simplest polygon in geometry, and the sum of its interior angles is always 180°. A triangle is formed by three line segments (edges) that intersect at three vertices, creating a two-dimensional re 13 min read Congruence of Triangles |SSS, SAS, ASA, and RHS RulesCongruence of triangles is a concept in geometry which is used to compare different shapes. It is the condition between two triangles in which all three corresponding sides and corresponding angles are equal. Two triangles are said to be congruent if and only if they can be overlapped with each othe 9 min read Theorem - Angle opposite to equal sides of an isosceles triangle are equal | Class 9 MathsIn geometry, an isosceles triangle is a triangle that has two sides of equal length. Sometimes it is specified as having exactly two sides of equal length, and sometimes as having at least two sides of equal length, the latter version thus including the equilateral triangle as a special case. Exampl 4 min read Triangle Inequality Theorem, Proof & ApplicationsTriangle Inequality Theorem is the relation between the sides and angles of triangles which helps us understand the properties and solutions related to triangles. Triangles are the most fundamental geometric shape as we can't make any closed shape with two or one side. Triangles consist of three sid 8 min read Chapter 8: QuadrilateralAngle Sum Property of a QuadrilateralAngle Sum Property of a Quadrilateral: Quadrilaterals are encountered everywhere in life, every square rectangle, any shape with four sides is a quadrilateral. We know, three non-collinear points make a triangle. Similarly, four non-collinear points take up a shape that is called a quadrilateral. It 9 min read QuadrilateralsQuadrilateral is a two-dimensional figure characterized by having four sides, four vertices, and four angles. It can be broadly classified into two categories: concave and convex. Within the convex category, there are several specific types of quadrilaterals, including trapezoids, parallelograms, re 12 min read Parallelogram | Properties, Formulas, Types, and TheoremA parallelogram is a two-dimensional geometrical shape whose opposite sides are equal in length and are parallel. The opposite angles of a parallelogram are equal in measure and the Sum of adjacent angles of a parallelogram is equal to 180 degrees.A parallelogram is a four-sided polygon (quadrilater 10 min read Rhombus: Definition, Properties, Formula and ExamplesA rhombus is a type of quadrilateral with the following additional properties. All four sides are of equal length and opposite sides parallel. The opposite angles are equal, and the diagonals bisect each other at right angles. A rhombus is a special case of a parallelogram, and if all its angles are 6 min read Trapezium: Types | Formulas |Properties & ExamplesA Trapezium or Trapezoid is a quadrilateral (shape with 4 sides) with exactly one pair of opposite sides parallel to each other. The term "trapezium" comes from the Greek word "trapeze," meaning "table." It is a two-dimensional shape with four sides and four vertices.In the figure below, a and b are 8 min read Square in Maths - Area, Perimeter, Examples & ApplicationsA square is a type of quadrilateral where all four sides are of equal length and each interior angle measures 90°. It has two pairs of parallel sides, with opposite sides being parallel. The diagonals of a square are equal in length and bisect each other at right angles.Squares are used in various f 5 min read Kite - QuadrilateralsA Kite is a special type of quadrilateral that is easily recognizable by its unique shape, resembling the traditional toy flown on a string. In geometry, a kite has two pairs of adjacent sides that are of equal length. This distinctive feature sets it apart from other quadrilaterals like squares, re 8 min read Properties of ParallelogramsProperties of Parallelograms: Parallelogram is a quadrilateral in which opposite sides are parallel and congruent and the opposite angles are equal. A parallelogram is formed by the intersection of two pairs of parallel lines. In this article, we will learn about the properties of parallelograms, in 9 min read Mid Point TheoremThe Midpoint Theorem is a fundamental concept in geometry that simplifies solving problems involving triangles. It establishes a relationship between the midpoints of two sides of a triangle and the third side. This theorem is especially useful in coordinate geometry and in proving other mathematica 6 min read Chapter 9: Areas of Parallelograms and TrianglesArea of a Triangle | Formula and ExamplesThe area of the triangle is a basic geometric concept that calculates the measure of the space enclosed by the three sides of the triangle. The formulas to find the area of a triangle include the base-height formula, Heron's formula, and trigonometric methods.The area of triangle is generally calcul 6 min read Area of Parallelogram | Definition, Formulas & ExamplesA parallelogram is a four-sided polygon (quadrilateral) where opposite sides are parallel and equal in length. In a parallelogram, the opposite angles are also equal, and the diagonals bisect each other (they cut each other into two equal parts).The area of a Parallelogram is the space or the region 8 min read Figures on the Same Base and between the Same ParallelsA triangle is a three-sided polygon and a parallelogram is a four-sided polygon or simply a quadrilateral that has parallel opposite sides. We encounter these two polynomials almost everywhere in our everyday lives. For example: Let's say a farmer has a piece of land that is in the shape of a parall 6 min read Like
